| Model |
PDI |
| Applied voltage for load cell |
DC 5V(350Ù maximum 8 possible connections) |
| Zeroing range |
0~2 mV/V |
| Input sensitivity |
0.5 uV/D (OIML, )Ntep, KS |
| 0.5 uV/D (Non OIML, )Ntep, KS |
| A/D internal resolution |
1/520,000 |
| A/D external resolution |
1/10,000 (NTEP, )OIML, KS |
| 1/20,000 (Non NTEP, )OIML, KS |
| (Possible with the use of sufficient output at 2mV/V L/C) |
| A/D conversion speed |
80 rounds/second |
| Sign for status |
STABLE, NET, ZERO, COM |
| Weight display |
LCD(6 digit + Sign) |
| AC Adapter |
AC 100~240 V(DC 12V, 1.25A) |
| Operating temperature |
-10℃ ~ 40℃ |
| Product size(mm) |
141(W) X 101(D) X 382(H) |
| Product weight |
500g |
| Product weight |
Standard |
COM1(RS-232 Printer & PC Interface ) |
| Option |
USB |
